Small size and light weight. Narrow beam orientation is accurate and wide beam direction coverage is good. Dynamic speed measurement can be used to measure the speed of the body and the target vehicle in motion. It is suitable for on-board moving speed measurement and lateral installation of overspeed capture system.

Product characteristics

1, narrow beam, designed radar beam for different applications, triggering accurate location and good universality.

2, frequency drift control technology, to ensure speed accuracy and reliability;

3, narrow beam microwave radar technology, accurate target location, avoid adjacent clutter interference.

4. Extreme speed response time to ensure target acquisition rate and real-time.

5, advanced radar signal processing and real-time data processing technology;

6, personalized and customizable interface type and working mode;

7, suitable for flexible and extensive application needs, and fully support the two development of customers.

8, low microwave radiation, low power consumption, long life, high stability, high reliability;

9. There is no need to destroy the pavement during installation and maintenance, and the detection performance is not affected by external environment such as light, dust, wind, rain, fog and snow.

1. Antenna type: planar microstrip array antenna

2, antenna beam width: 5.5 degrees x 21 degrees.

3, working frequency: 24.15GHz

4, high frequency error: less than or equal to 40MHz

5. Working temperature range: -40 C ~+70 C; working humidity range: 5%RH~95%RH

6, speed range: (2~400) km/h; speed measurement accuracy: (-1~0) km/h

7, reaction time: less than 25ms

8, dynamic speed measurement: support

9, power supply: (9-16) VDC

10, communication interface: full duplex RS232 or half duplex RS485

11, size: 146mmX84mmX44mm
