This is not a simple access control, this is a graphical user-defined programming support, a collection of access control and PLC programmable fun controller. Support no need to carry inductive card, mobile phone can open the door. Even if you do not install PC access control software, you can manage your access control by APP alone.

Control gate number:             1 door bidirectional

Number of cards:                    20000

Offline events:                         20000

Communication mode:           TCP/IP networking

Working voltage:                    DC 10V-15V (recommended 12V)

Working current:                    < 400mA

Working temperature:            -20 ~ 70 degrees

Motherboard size:                  156mm * 102mm

Chassis size:                            340mm * 252 * 70mm

Chassis power supply:            12V/5A switching power supply

Number of card readers:        2 Wiegand card readers

Go out button:                        1

Gate input:                              1

Lock output:                            1
